BG545R

Features and Functionalities BG545R

• The operating speed is 1.5s, and the speed can be adjusted according to different
  boom arm lengths.
• Reversible left and right directions.
• The transmission mechanism is simple, compact, and easy to install on-site.
• Interactive and stylish chassis LED design.
• Equipped with digital control monitoring, thus supports delay in automatic close, automatic test, rise/fall output status display.
• Supports automatic power-off, manual rise of the boom arm, anti-smash, and fire linkage functions.
• The angle of rise/fall of the arm can be adjusted, and the digital encoder is adopted to limit the position automatically, thus replacing the traditional limiting procedure. The position control is accurate.
• 24V backup battery can be used to ensure the normal operation of the barrier when power is off.
• The chassis is made of a 2.0mm metal sheet through an electrophoretic and powder spraying process.
• The boom will bounce back when it is blocked.

Parameters BG545R

• Dimensions 350 * 300 * 1020 (mm)
• Motor Type DC 24V brushless motor
• Motor MCBF 3 million times
• Output Power 120W
• Rated Current 6A
• Power Supply AC 220V, 50Hz / AC 110V, 60Hz
• Remote Control Distance ≤ 30m
• Operating Temperature -35°C to 70°C
• Operating Humidity < 90%
• Weight 45kg
